RUBSEAL™ ADHESIVE & SEALANT

Partel RUBSEAL™ is a high performance, one component, adhesive & sealant engineered for internal and external applications requiring certified fire resistance and long term joint movement. It is designed for use in expansion joints, façade connections, and penetration seals where fire performance, elasticity, and weather durability are critical.

Typical Use Cases Include

• Expansion joints and linear connections in fire rated façade, wall, and slab assemblies

• Sealing around fire doors, curtain wall systems, and external façades

• Penetration sealing for pipes, conduits, and cable lead throughs requiring fire protection

• Construction joints exposed to movement, vibration, and extreme weather conditions

• External sealing of PVC elements, façade panels, and modular connections

Why Partel RUBSEAL™?

• Fire resistant sealant tested to UNE EN 1366-4 and classified to EN 13501-2 providing up to EI 240 fire protection

• Reaction to fire classification B-s3, d0 to EN 13501-1 for low smoke and non dripping behaviour

• High elasticity with movement capability up to ±25 percent in accordance with ISO 11600 F25 LM and G25 LM

• Excellent resistance to UV exposure, moisture, and extreme temperature fluctuations

• Strong adhesion without primer to concrete, brick, metal, PVC, and common construction substrates

• Neutral curing system that is non corrosive to steel and aluminium

• Long term durability resisting cracking, shrinkage, and loss of adhesion

• A+ certified for very low VOC emissions with a solvent free formulation

• Ready to use one component RTV system for clean and efficient installation

Application

Suitable for permanent fire rated and flexible sealing of:

• Expansion and movement joints

• Façade and curtain wall connections

• Fire stop joints and service penetrations

• Internal and external construction joints

Suitable for:

• Concrete and masonry

• Brickwork

• Metal substrates including steel and aluminium

• PVC elements

• Façade panels and modular systems

Application Guidelines

• Ensure substrates are clean, dry, and free from dust, grease, oil, or cement residues

• Use Partel ACRAPRIME on highly porous or stressed substrates where required

• Joint width must be between 5 mm and 35 mm

• Joint width should be at least four times the expected movement

• For joints wider than 16 mm, joint depth should be approximately half the width

• Prevent three sided adhesion using closed cell polyethylene backing rod or mineral wool backing

• Apply using a standard sealant gun and smooth before skin formation

Technical Performance

• Movement capability: ±25 percent

• Tensile strength: 1.1 MPa

• Elongation at break: 600 percent

• Elastic recovery: 90 percent

• Fire resistance: Up to EI 240

• Reaction to fire: B-s3, d0

• VOC emission: A+ certified

• Application temperature: +5°C to +50°C

• Service temperature: -50°C to +150°C

Packaging & Storage

• Available in 310 ml cartridges

• Store in cool dry conditions between +5°C and +25°C

• Protect from frost
